Parker BVHP04SSS1N Ball Valve 1/4 Inch Sae 10000 Psi

Product Description

The PARKER BVHP04SSS1N is a standard manual ball valve designed for high-pressure hydraulic and fluid-system applications. Built with a carbon steel body and carbon steel trim, it handles working pressures up to 10000 psi, making it suited for demanding industrial and mobile hydraulic circuits. The 1/4 inch SAE x SAE end connections provide a secure, leak-resistant interface compatible with standard SAE straight-thread ports. A lever handle allows for quick quarter-turn shutoff, giving technicians direct, tactile control over flow. The Delrin seal material offers reliable sealing performance across a working temperature range starting at 35 degrees F. Licensed plumbers, pipefitters, and hydraulic system technicians are the typical installers of this valve.

This valve is intended for use in hydraulic lines, fluid power circuits, and high-pressure plumbing installations where a reliable manual shutoff is required. The 1/4 inch pipe size and SAE x SAE thread configuration make it a practical fit for compact hydraulic assemblies, test stands, and mobile equipment circuits. It is sold as a single unit. Applications calling for a robust, full-port manual ball valve at the 1/4 inch line size will find this valve appropriate for both original installations and service replacements in high-pressure environments.

Key Features

• Rated to 10000 psi maximum working pressure for demanding hydraulic service
• Carbon steel body and trim provide strength and durability in industrial environments
• SAE x SAE end connections with 7/16-20 thread size for standard hydraulic port fitment
• Lever handle design enables fast quarter-turn manual actuation
• Delrin seal material delivers consistent sealing performance
• Minimum operating temperature of 35 degrees F suits most standard hydraulic fluid applications

Compatibility

Designed as an OEM-style replacement or new-installation manual ball valve for 1/4 inch SAE straight-thread hydraulic lines and fluid power circuits requiring up to 10000 psi working pressure.

Installation Notes

Installation should be performed by a qualified pipefitter, hydraulic technician, or licensed plumber. Depressurize and isolate the hydraulic circuit completely before removing any existing valve or fitting. Verify that mating SAE port threads are clean and undamaged before assembly, and apply thread sealant only if specified by the system designer. Follow all applicable ASME and fluid power safety standards when working on high-pressure hydraulic systems.
