Parker BVHC20-20F Hydraulic Hose Valve Fitting 1-1/4 in Npt

Product Description

The PARKER BVHC20-20F is a straight brass valve fitting designed for hydraulic hose assemblies operating in demanding fluid-power applications. It carries a maximum working pressure of 350 psi and accepts a 1-1/4 inch NPT threaded connection on both ends. The fitting measures 3.54 inches in overall length and features a 1-1/4 inch body diameter. Built from solid brass, it delivers reliable sealing performance across a wide service temperature range of -35 degrees F to 250 degrees F. Licensed technicians and fluid-power mechanics rely on this fitting where a durable, straight-run valve connection is required in mobile or industrial hydraulic circuits.

The BVHC20-20F is suited for industrial hydraulic lines, mobile equipment hydraulic systems, and water and coolant lines. Its NPT threaded interface makes it compatible with standard pipe-thread ports found throughout these systems. The straight configuration simplifies installation in tight plumbing runs where elbow or angled fittings are not required. It is packaged individually and is appropriate for both new installations and field replacements on existing hydraulic circuits.

Key Features

• 350 psi maximum working pressure for industrial hydraulic service
• Brass construction for corrosion resistance in water, coolant, and hydraulic fluid environments
• 1-1/4 inch NPT threaded connection on both ends for standard pipe-thread compatibility
• Straight body shape simplifies inline installation
• Wide temperature range: -35 degrees F to 250 degrees F
• 3.54 inch overall length with 1-1/4 inch body diameter

Compatibility

Designed for use with industrial hydraulic lines, mobile equipment hydraulic systems, and water and coolant lines requiring a 1-1/4 inch NPT threaded straight valve fitting.

Installation Notes

Installation should be performed by a qualified hydraulic technician or pipefitter familiar with NPT thread engagement and hydraulic system safety procedures. Depressurize and fully isolate the hydraulic circuit before removing or installing any fitting. Apply appropriate thread sealant compatible with the system fluid — do not overtighten NPT connections, as brass fittings can crack under excessive torque. Verify that the system operating pressure does not exceed the 350 psi rating of this fitting before returning the circuit to service.
