Parker BD-1J94312-10-1 Hydraulic Hose Fitting 90 Elbow

Product Description

The PARKER BD-1J94312-10-1 is a short drop female Seal-Lok swivel 90-degree elbow fitting designed for hydraulic hose assemblies. Built from steel with a threaded connection type, this Series 43 fitting accepts a hose with a 0.625-inch inside diameter (size 10) and a 3/4-inch thread size. The 90-degree elbow configuration allows routing hydraulic lines in tight quarters where straight fittings cannot make the turn. It is intended for use by hydraulic system technicians and fluid power professionals assembling or servicing high-pressure hydraulic circuits on mobile or industrial equipment.

This fitting is rated for use with a wide range of Parker hydraulic hoses, including the 187, 302, 304, 387, 422, 424, 426, 436, 471TC, 471ST, 472TC, 482TC, 482ST, 487, 722, 787, 797, and 881 hose series. The short drop geometry keeps the assembly compact, reducing stress on the hose near the connection point. Typical applications include mobile equipment hydraulics, industrial machinery, and any system requiring a directional change at the hose-to-port interface.

Key Features

• Short drop female Seal-Lok swivel design allows hose rotation during assembly without twisting the hose
• 90-degree elbow configuration routes hose lines in confined or angled installation environments
• Steel construction provides durability in high-pressure hydraulic service
• Threaded connection type with 3/4-inch thread size for secure port engagement
• Meets ISO 12151-1 standards for hydraulic fluid power hose fittings
• California Proposition 65 compliant

Compatibility

Compatible with Parker 187, 302, 304, 387, 422, 424, 426, 436, 471TC, 471ST, 472TC, 482TC, 482ST, 487, 722, 787, 797, and 881 hydraulic hose series with a 10 mm (0.625-inch ID) hose size.

Installation Notes

Installation should be performed by a qualified hydraulic technician or fluid power specialist. Depressurize and bleed down the hydraulic system fully before disconnecting any fittings or hose assemblies. Use the correct Seal-Lok assembly tooling and verify thread engagement meets the fitting manufacturer's recommended procedure. Inspect the sealing face and O-ring seat for contamination or damage before making up the connection.
