PARKER 940081 Electronic Evaporator Pressure Regulating Valve

Product Description

The PARKER 940081 is an electronic evaporator pressure regulating valve used for accurate temperature control within evaporators. This valve manages refrigerant flow based on data received from a controller and sensor.

• Regulates refrigerant flow for efficient temperature management.
• Includes balanced ports and utilizes a step motor for precision.
• Operates with an external controller, eliminating pilot lines.

Product Highlights

This product features a sturdy cartridge design, allowing for the easy replacement of moving parts and facilitating maintenance tasks.

Product Information

Standard Information

• Brand: Parker Sporlan
• MPN: 940081

Technical Specifications

• Body Material: Brass
• Composition: Brass, Copper, Stainless Steel
• Connection Type: ODF
• Inlet Connection Size: 1-1/8 inches
• Outlet Connection Size: 1-1/8 inches
• Port Diameter: 1-1/8 inches
• Refrigerant Compatibility: R-134a, R-404A, R-407C, R-410A, R-507A
• Maximum Temperature: 240°F (115.56°C)
• Temperature Range: -50°F to 140°F (-45.56°C to 60°C)
• Overall Length: 7.24 inches
• Weight: 3.68 pounds
• Dimensions: Length: 12 inches, Height: 3.25 inches, Width: 8.5 inches
• Country of Origin: USA
