Parker 821FR-12-WHT-RL Push-on Air Hose 3/4 in 250 Psi

Product Description

The PARKER 821FR-12-WHT-RL is a push-on air hose designed for compressed air distribution in industrial and trade service environments. Built from synthetic rubber, this hose carries a 3/4 inch inside diameter and a 1.03 inch outside diameter, with a working pressure rating of 250 psi. The white exterior aids visibility in shop and field installations. It is sold in 1-foot increments with a 20-foot minimum cut length from a 200-foot coil, making it well-suited for custom runs where standard pre-cut lengths are not practical. HVAC technicians, pneumatic tool operators, and industrial maintenance crews are the typical installers.

This hose is intended for compressed air service in both light commercial and industrial settings. The push-on end connection style allows for fast assembly with compatible push-on fittings without the need for clamps or crimp tooling at the hose connection point. The wide temperature range of -40 degrees F to 212 degrees F supports year-round use in unconditioned spaces, outdoor runs, and high-temperature shop environments. It is a cut-to-length product, so field technicians can size runs precisely to the application without waste.

Key Features

• 3/4 inch inside diameter for high-flow compressed air service
• 250 psi working pressure rating
• Operating range of -40 degrees F to 212 degrees F
• Synthetic rubber construction for flexibility and durability
• Push-on end connection style — no clamps or crimp tooling required at hose end
• White color for easy identification in multi-line installations
• Sold in 1-foot increments; 20-foot minimum cut length per order

Compatibility

Designed for use with standard push-on air fittings compatible with 3/4 inch ID hose in compressed air service applications. No specific system or model compatibility was provided by the manufacturer for this SKU.

Installation Notes

Installation is typically performed by industrial maintenance technicians or licensed mechanical contractors working on compressed air distribution systems. Depressurize and lock out the air supply before cutting or connecting hose sections. Push-on fittings must be fully seated to achieve rated pressure performance. Verify that all fittings and downstream components are rated for at least 250 psi before pressurizing the completed assembly.
