Parker 8010-5 Female Pipe Rigid Hydraulic Fitting 3000 Psi

Product Description

The PARKER 8010-5 is a female pipe rigid hydraulic hose fitting designed for high-pressure hydraulic fluid circuits. Built from steel with a straight body configuration, it connects 1/2 inch hydraulic hose to 3/4 inch NPTF threaded ports at a maximum working pressure of 3,000 psi. The NPTF thread form creates a pressure-tight mechanical seal without relying solely on sealant tape or compound. With an overall length of 2.14 inches and a body diameter of 1/2 inch, this fitting is suited for tight plumbing runs where a compact, rigid connection is required. It supports a maximum flow rate of 12.00 GPM, making it appropriate for moderate-flow hydraulic circuits. Licensed hydraulic technicians and equipment mechanics are the primary installers.

This fitting is designed for use in add-on hydraulic circuits, hydraulic loaders, and hydraulic tools. It is part of Parker Series 4000 and conforms to ISO 5675 standards. It is well suited to both mobile equipment hydraulics and stationary hydraulic tool circuits where a secure, rigid female pipe connection is needed. The straight geometry allows direct in-line plumbing from hose to port without angular offset. It is sold individually with a minimum order quantity of one.

Key Features

• 3,000 psi maximum working pressure for high-pressure hydraulic service
• NPTF threaded connection provides a pressure-tight mechanical seal
• Steel construction for durability in demanding hydraulic environments
• Straight body shape simplifies in-line plumbing layouts
• ISO 5675 compliant — Parker Series 4000
• Supports up to 12.00 GPM maximum flow rate

Compatibility

Designed for use with add-on hydraulic circuits, hydraulic loaders, and hydraulic tools requiring a 1/2 inch hose to 3/4 inch NPTF rigid female pipe connection rated to 3,000 psi.

Installation Notes

Installation should be performed by a qualified hydraulic technician or equipment mechanic. Depressurize and de-energize the hydraulic system completely before removing or installing any fittings. NPTF threads are designed for dry-seal engagement, but follow the equipment manufacturer's guidance on thread sealant use. Inspect threads and sealing surfaces for damage before torquing to final position.
