Parker 8 Tlfa Mandrel Seal Assembly Mandrel Orfs

Product Description

The PARKER 8 TLFA MANDREL is a compression tube Fastseal seal assembly mandrel used to install O-ring face seal (ORFS) and flat-face tube end fittings in hydraulic and fluid power lines. Constructed from steel, this mandrel provides the mechanical support needed to properly seat ORFS seals during assembly. It is designed for use with the PARKER 8 TLFA-S seal assembly and is a precise tool component for technicians working on tube fitting systems that require leak-free, flat-face connections.

This mandrel is suited for hydraulic system assembly in industrial, mobile equipment, and fluid power applications where ORFS flat-face tube fittings are specified. It is typically used by hydraulic system technicians and pipefitters during new installation or when replacing seal components on existing tube runs. The compact dimensions make it practical for bench work and field service on tubing assemblies.

Key Features

• Steel construction provides durability for repeated use in seal installation tasks
• Designed for flat-face, ORFS, and tube end connections
• Specifically compatible with PARKER 8 TLFA-S Fastseal seal assemblies
• Compact form factor suitable for bench and field assembly work
• Single-piece mandrel simplifies the seal seating process on tube ends

Compatibility

Designed for use with the PARKER 8 TLFA-S Fastseal seal assembly on flat-face ORFS tube end fittings.

Installation Notes

Installation is performed by hydraulic system technicians or pipefitters. Depressurize and isolate the hydraulic circuit completely before disassembling any tube fittings or replacing seal components. Use the mandrel as directed by the fitting manufacturer instructions to ensure proper seal seating without damaging the O-ring. Follow applicable fluid power system codes and the fitting manufacturer torque guidelines when reassembling the tube connection.
