Parker 8-6 V5OLO-S 45 Deg Male Elbow Orfs Sae-orb 6000 Psi

Product Description

The PARKER 8-6 V5OLO-S is a 45-degree male elbow compression tube fitting designed for high-pressure hydraulic and fluid power lines. It connects a 1/2-inch OD tube on the compression side to a male SAE O-Ring Boss (SAE-ORB) port on the body side using an O-Ring Face Seal (ORFS) end connection. Rated to 6000 psi maximum working pressure, this fitting is built from zinc-plated steel for corrosion resistance in demanding service environments. It is installed by hydraulic technicians, fluid power specialists, and industrial maintenance mechanics working on high-pressure tubing assemblies.

This fitting is suited for hydraulic systems, mobile equipment, and industrial fluid power circuits where a 45-degree directional change is required between a tube run and a threaded port. The ORFS x SAE-ORB dual-end configuration makes it a common choice when routing 1/2-inch OD steel or hydraulic tubing into SAE-ORB manifold ports or valve blocks. It is appropriate for both new assembly and field repair work where a leak-free, high-pressure elbow connection is required at the port face.

Key Features

• 45-degree male elbow geometry for direction changes in tight tubing runs
• ORFS x SAE-ORB end connections for compatibility with O-ring face seal and O-ring boss port interfaces
• 6000 psi maximum working pressure rating for high-pressure hydraulic service
• 9/16-18 UNF thread size on the male SAE-ORB end
• 1/2-inch tube outside diameter on the compression end
• Zinc-plated steel construction for corrosion resistance in industrial environments

Compatibility

Designed as an OEM-style replacement or new-installation fitting for high-pressure hydraulic tube assemblies using 1/2-inch OD tubing terminated at SAE-ORB threaded ports.

Installation Notes

Installation should be performed by a qualified hydraulic technician or fluid power mechanic. Depressurize and isolate the hydraulic circuit completely before removing or installing any fittings. Inspect the O-ring and sealing faces for nicks or contamination before assembly, as ORFS connections rely on face-seal integrity to hold rated pressure. Follow the fitting manufacturer's assembly instructions for proper tube preparation and nut engagement; do not over-torque the compression nut, as this can damage the tube or fitting body.
