PARKER 7510501 Bronze Ball Valve Inline FNPT 1 In

Product Description

The PARKER 7510501 is a manual ball valve with a bronze body and a brass ball. This inline valve has FNPT connections for two-inch pipes. It is suitable for air and steam applications. The design includes a locking lever for secure operation.

• Maximum operating pressure: Six hundred psi
• Body style: Inline with standard port
• Valve size: One inch

Product Highlights

This valve offers reliable performance for air flow control, making it ideal for HVAC and plumbing applications.

Product Information

Standard Information

• Type: Ball Valve
• Material: Bronze body, Brass ball

Technical Specifications

• Connection type: FNPT
• Temperature range: Minus twenty degrees Fahrenheit to plus four hundred fifty degrees Fahrenheit
• Maximum steam pressure: One hundred fifty psi
• Dimensions: Five point forty-nine inches length, one point fifty-nine inches width, three inches height
• Handle type: Locking lever
• Warranty: Five years
• Valve body color: Bronze
• Series: 75 Series Ball Valves
