PARKER 73A10527A Ball Valve with Latch Lever - 1 inch NPT Connection

Product Description

The PARKER 73A10527A is a durable ball valve designed for reliable operation. This valve features a latch lever that allows for easy control. It has a 1-inch NPT connection and is crafted with a steel body and stainless steel ball and spindle. The valve is part of the 73A Series and employs a 2-part housing construction, suitable for a range of applications in straight-line configurations.

• Connection Type: FNPT
• Maximum Pressure: 2000 psi
• Temperature Range: -20°F to 550°F

Product Highlights

The PARKER 73A10527A ball valve is ideal for high-pressure applications. The stainless steel components ensure longevity and resistance to corrosion.

Product Information

Standard Information

• Item: Ball Valve
• Handle Type: Lever

Technical Specifications

• Ball Material: Stainless Steel
• Body Material: Steel
• Dimensions: 5 x 1.18 x 1.78 inches
• Series: 73A Series
• Shape: Straight
• Spindle Material: Stainless Steel
• Max. Temperature: 550°F
• Min. Temperature: -20°F
