Parker 73419AN2NN00 Skinner 4-Way 2 Position Single Solenoid Aluminum Vessel

Product Description

The Parker Skinner 73419AN2NN00 is a 4-way, 2-position single solenoid aluminum vessel. It is designed for applications requiring the actuation of double-acting cylinders and piloting of control pressure vessels.

• 4-way direct-acting and pilot-operated vessel
• Compatible with lubricated air, inert gases, water, and light oil
• Mounts in any position; optimal with coil vertical and upright

Product Highlights

Parker's 73419AN2NN00 features pilot-operated and direct-acting mechanisms, enabling robust control in industrial settings such as oil and gas, double-acting cylinder control, air motors, and damper control. It is SIL-3 capable and UL Listed for certain models.

Product Information

Standard Information

• Brand: Parker Fluid Control
• MPN: 73419AN2NN00

Technical Specifications

• Dimensions: 8 inches length, 3.1 inches width, 2.7 inches height
• Weight: 1.18 lbs
• Standard Voltages: AC 24/60, 120/60, 110/50, 240/60, 220/50; DC 12, 24, 120
• Max Ambient Temperature: 167°F
• Min Ambient Temperature: -40°F
• Coil Classification: Class F standard, Class H available
• Agency Approvals: UL Listed, CSA Certified
