Parker 71315SN2GV00 Solenoid Valve 1/4 Inch Npt

Product Description

The PARKER 71315SN2GV00 is a normally closed solenoid valve designed for precise fluid or gas flow control in industrial and commercial systems. The valve body is constructed from stainless steel for corrosion resistance, and the FKM fluorocarbon seal provides compatibility with a wide range of media. The 1/4 inch NPT port connects to standard threaded pipe or tubing. With a Cv factor of 0.11 and a 1/16 inch orifice, this valve is suited for low-flow applications requiring reliable shutoff. Note that an integrated coil is required separately to complete the valve assembly. A licensed technician or qualified industrial service professional handles installation.

This valve is appropriate for use in HVAC, refrigeration, chemical processing, or fluid handling systems where a compact, normally closed solenoid valve is required. The stainless steel body makes it well suited for environments with exposure to aggressive media or elevated humidity. The NPT thread standard allows direct installation into standard pipe fittings commonly found in residential and light commercial mechanical systems. Maximum operating temperature is 185 degrees F, and the valve operates at a minimum pressure differential of 0 psi, allowing it to open under no-differential-pressure conditions when the coil is energized.

Key Features

• Normally closed valve state ensures flow is shut off when the coil is de-energized
• Stainless steel body provides corrosion resistance for demanding service environments
• FKM fluorocarbon seal material compatible with a broad range of fluids and gases
• 1/4 inch NPT port fits standard threaded piping connections
• Cv factor of 0.11 with 1/16 inch orifice for controlled low-flow applications
• Zero minimum operating pressure differential allows function in low-pressure systems

Compatibility

Designed as an OEM-style replacement or new-installation solenoid valve for systems requiring a 1/4 inch NPT normally closed solenoid valve with stainless steel construction. Requires a separately sourced integrated coil for complete valve operation.

Installation Notes

Installation should be performed by a licensed plumber, HVAC technician, or qualified industrial mechanic familiar with solenoid valve systems. De-energize the system and isolate the line pressure before removing or installing the valve. Apply appropriate thread sealant to NPT connections per IPC or IFGC guidelines as applicable. Do not energize the valve until the coil assembly is fully installed and all connections are secure.
