Parker 71295SN1KNJ1 Solenoid Valve 1/8 Inch Npt

Product Description

The PARKER 71295SN1KNJ1 is a direct-acting, normally open solenoid valve designed for precise fluid or gas control in industrial and commercial systems. Built with a stainless steel body and NBR seal, it handles a maximum working pressure of 250 psi and operates across a wide range of voltages including 12Vdc, 24Vdc, 24/60Vac, 120Vdc, 120/60 to 110/50Vac, and 240/60 to 220/50Vac. The 1/8 inch NPT port and 3/32 inch orifice make it suited for low-flow applications. An integrated coil is included, though the valve requires that coil for complete operation. Maximum operating temperature is 185 degrees F.

This valve is appropriate for use in HVAC control circuits, pneumatic systems, fluid handling lines, and process control applications where a normally open state is required at rest. Its compact form factor, with an overall length of 2.76 inches and overall height of 3.65 inches, fits tight plumbing or panel installations. The multi-voltage rating allows a single part to serve diverse electrical environments, reducing stocking complexity for service contractors and OEM integrators alike. A minimum operating pressure differential of 0 psi allows it to function in low-pressure or gravity-fed systems.

Key Features

• Direct-acting, normally open valve — energizing the coil closes the valve
• Stainless steel body for corrosion resistance in demanding fluid environments
• NBR seal rated to 185 degrees F maximum temperature
• Multi-voltage coil compatibility: 12Vdc, 24Vdc, 24/60Vac, 120Vdc, 120/60 to 110/50Vac, 240/60 to 220/50Vac
• Zero minimum operating pressure differential — works in low-pressure and gravity-fed lines
• CSA Certified, UL Listed, and NEMA 4X rated for wet and washdown environments

Compatibility

Designed as a direct-acting solenoid valve for industrial, commercial HVAC, and process control plumbing systems using 1/8 inch NPT threaded connections. Confirm coil voltage matches the control circuit before installation.

Installation Notes

Installation should be performed by a qualified technician familiar with fluid or pneumatic system service. Shut off system pressure and de-energize all control circuits before beginning work. Apply thread sealant appropriate for the media being controlled and torque fittings per the fitting manufacturer's recommendations. Verify coil voltage matches the supply before energizing the valve.
