Parker 71215SN1SN00 Solenoid Valve 1/8 Inch Npt

Product Description

The PARKER 71215SN1SN00 is a direct-acting, normally closed solenoid valve designed for precise fluid control in industrial and commercial systems. Built with a stainless steel body and NBR seal, this valve handles a wide range of media and operating conditions. It accepts multiple voltage inputs including 12 Vdc, 24 Vdc, 24/60 Vac, 120 Vdc, 120/60 to 110/50 Vac, and 240/60 to 220/50 Vac, making it adaptable to varied control circuits. The 1/8 inch NPT port and a Cv rating of 0.500 suit low-flow applications where accurate shutoff is required. Licensed HVAC technicians, industrial mechanics, and fluid system specialists are the typical installers.

This valve fits residential and light commercial fluid control applications where a compact, direct-acting normally closed valve is needed. Its stainless steel construction makes it appropriate for mildly corrosive media or sanitary environments. The multi-voltage coil compatibility allows integration into a range of control panel configurations without requiring a separate transformer in most cases. Systems that require zero minimum operating pressure differential benefit from the direct-acting design, which opens fully without relying on line pressure to assist actuation.

Key Features

• Direct-acting, normally closed operation with zero minimum operating pressure differential
• Stainless steel body for corrosion resistance in demanding media applications
• NBR seal compatible with a broad range of fluids
• Multi-voltage coil: 12 Vdc, 24 Vdc, 24/60 Vac, 120 Vdc, 120/60 to 110/50 Vac, and 240/60 to 220/50 Vac
• Cv rating of 0.500 with a 3/16 inch orifice for controlled low-flow performance
• CSA Certified, UL Listed, and NEMA 4X rated for use in wet or washdown environments

Compatibility

Designed as a direct-acting normally closed replacement solenoid valve for 1/8 inch NPT fluid control systems operating within the listed voltage and pressure parameters. Note that an integrated coil is required for complete valve assembly and must be specified separately if not already sourced.

Installation Notes

Installation should be performed by a qualified technician familiar with fluid control systems and applicable codes. De-energize all electrical circuits and shut off the upstream fluid supply before beginning installation or service. Verify that the selected coil voltage matches the control circuit before energizing. Ensure pipe threads are clean and properly sealed with an appropriate thread sealant rated for the media being controlled.
