Parker 71215SN1MN00 Solenoid Valve 1/8 Inch Npt

Product Description

The PARKER 71215SN1MN00 is a direct-acting, normally closed solenoid valve designed for precise fluid and gas control in industrial and commercial systems. It features a 1/8 inch NPT port, a stainless steel body, and an NBR seal, making it suitable for demanding media compatibility requirements. The valve operates across a wide range of voltages including 12 Vdc, 24 Vdc, 120 Vdc, 24/60 Vac, 120/60 to 110/50 Vac, and 240/60 to 220/50 Vac. With a maximum working pressure of 200 psi and a Cv factor of 0.28, it delivers reliable, repeatable shutoff for low-flow applications. Licensed HVAC technicians, plumbers, and industrial maintenance professionals are the typical installers.

This valve is suited for residential and light commercial applications where a compact, corrosion-resistant normally closed shutoff is required. The 1/8 inch NPT thread makes it compatible with standard pipe fittings in fluid handling, pneumatic control, and process automation systems. The zero minimum operating pressure differential allows it to function in gravity-fed or low-pressure systems without requiring a pressure drop to actuate. Note that this valve requires an integrated coil for complete assembly; verify coil compatibility before ordering.

Key Features

• Direct-acting operation with zero minimum pressure differential — works in low-pressure and gravity-fed systems
• Stainless steel body provides corrosion resistance for aggressive media and wash-down environments
• NBR seal material compatible with a wide range of fluids and gases
• Multi-voltage coil compatibility: 12 Vdc, 24 Vdc, 120 Vdc, 24/60 Vac, 120/60 to 110/50 Vac, 240/60 to 220/50 Vac
• Normally closed design ensures failsafe shutoff on power loss
• CSA Certified, UL Listed, and NEMA 4X rated for wet and outdoor enclosure environments

Compatibility

Designed as an OEM-style replacement or new-installation solenoid valve for systems requiring a 1/8 inch NPT direct-acting normally closed valve with stainless steel construction. Requires a separately sourced integrated coil for complete valve operation.

Installation Notes

Installation should be performed by a licensed plumber, HVAC technician, or qualified industrial maintenance technician familiar with the applicable fluid or gas system. De-energize the system and relieve all line pressure before removing or installing the valve. Apply thread sealant appropriate for the media being controlled and torque fittings according to the fitting manufacturer specifications. Verify coil voltage matches the available supply voltage before energizing the assembly.
