PARKER 7060301 Bronze Ball Valve - 3-Way FNPT, 1/2 Inch

Product Description

The PARKER 7060301 is a two-piece bronze ball valve with FNPT connections on all ports. This valve allows for efficient flow regulation among three pipe sections. The chrome-plated brass ball ensures durability, while the zinc-plated steel lever handle features a vinyl grip for easy manual operation. The blow-out proof stem design enhances safety, and PTFE seals along with RPTFE seats help to minimize leakage.

• FNPT connections provide secure sealing.
• Supports WOG pressures up to 400 psi.
• Operates in a temperature range of -20 to 450 degrees Fahrenheit.

Product Highlights

This valve is suitable for various plumbing and HVAC applications, facilitating smooth water flow and reliable performance.

Product Information

Standard Information

• Item: Ball Valve
• Model: 70-603-01

Technical Specifications

• Ball Material: Brass
• Ball Finish: Chrome Plated
• Connection Type: FNPT
• Dimensions: 5.25 inches x 2 inches x 2.25 inches
• Maximum Medium Temperature: 500°F
• Operating Pressure: 400 psi
• Seal Material: PTFE
• Number Of Ways: 3
• Nominal Valve Size: 1/2
