Parker 7010701 Bronze Ball Valve - 1-1/2 FNPT

Product Description

The Parker 7010701 is a two-piece, inline ball valve made of bronze. It has female National Pipe Thread (FNPT) connections on both ends, measuring one and one-half inches. This valve features a standard port and a lever handle for manual operation. It is designed for use with steam and operates within a temperature range from negative twenty degrees Fahrenheit to four hundred fifty degrees Fahrenheit.

• Body Material: Bronze
• Connection Type: 1-1/2 FNPT x FNPT
• Maximum Pressure: 600 psi WOG

Product Highlights

The Parker 7010701 is ideal for applications involving steam and various other media. It provides reliability and durability in performance.

Product Information

Standard Information

• Item: Ball Valve
• Body Style: Inline

Technical Specifications

• Ball Material: Bronze
• Maximum Pressure (steam): 150 psi
• Temperature Range: -20°F to +450°F
• Valve Construction: Two-Piece
• Handle Type: Lever
• Valve Size: 1 1/2
• Seal Material: PTFE
• Stem Material: Brass
