PARKER 7010401 Bronze Ball Valve Inline FNPT 3/4 Inch

Product Description

The PARKER 7010401 is a bronze ball valve with a three-fourth inch inline female National Pipe Thread Tapered connection. It features a two-piece housing for durability and a lever handle for manual operation. This valve is optimal for standard port flow and is rated for use with steam.

• Two-piece bronze construction ensures longevity.
• Manual lever handle for user-friendly operation.
• PTFE seal and seat enhance reliability with steam applications.

Product Highlights

This bronze ball valve is designed for effective flow control in plumbing and various industrial systems.

Product Information

Standard Information

• Item: Ball Valve
• Connection Type: FNPT

Technical Specifications

• Body Material: Bronze
• Nominal Valve Size: 3/4 inch
• Max. Operating Pressure: 600 psi
• Max. Steam Pressure: 150 psi
• Seal Material: PTFE
• Diameter of Connection: 1.05 inches
• Temperature Range: -20°F to 500°F
• Dimensions: 7.45 x 2.76 x 4.43 inches
