Parker 66PLP-10M-6G Push-to-connect Elbow Fitting

Product Description

The PARKER 66PLP-10M-6G is a push-to-connect elbow tube fitting designed for fast, tool-free connections in pneumatic and fluid systems. It accepts a 10mm outside-diameter tube on the push-in end and connects to a female BSPP threaded port on the other. The body is nickel-plated brass, rated for a maximum working pressure of 300 psi and a temperature range of 0 degrees F to 200 degrees F. A yellow release button allows quick tube removal without special tooling. The fitting meets the UL94 V-0 flame resistance standard and uses silicone-free grease, making it suitable for applications where silicone contamination is a concern. Plumbers, HVAC technicians, and industrial maintenance professionals install this type of fitting.

This elbow fitting is used wherever a 90-degree directional change is needed in a push-to-connect pneumatic or fluid line. It is well-suited for residential and light commercial HVAC controls, compressed air distribution, and process fluid plumbing where BSPP female port connections are present. The compact 1.54-inch overall length keeps installation tight in panel or cabinet environments. The silver nickel-plated finish resists corrosion in light-duty wet or humid service conditions.

Key Features

• Push-to-connect design accepts 10mm OD tubing with no tools required
• Yellow release button allows fast, secure tube removal and reinsertion
• Nickel-plated brass body rated to 300 psi maximum working pressure
• Temperature range of 0 degrees F to 200 degrees F
• BSPP female thread type for compatibility with metric-standard port connections
• Silicone-free grease construction for sensitive system environments
• Meets UL94 V-0 flame resistance standard

Compatibility

Designed as an OEM-style push-to-connect elbow fitting for pneumatic and fluid systems using 10mm OD tubing and female BSPP threaded ports.

Installation Notes

Depressurize and de-energize the system fully before removing or installing any push-to-connect fitting. Ensure tube ends are cut cleanly and squarely with no burrs before insertion to achieve a proper seal. Thread engagement at the female BSPP port should be made hand-tight and then snugged with a wrench to the hex flats — do not overtighten. Follow applicable local plumbing or mechanical codes when installing fittings in pressurized fluid or air systems.

WARNING: This product can expose you to chemicals including lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
