Parker 66PLP-10M-4G Push-to-connect Elbow Fitting

Product Description

The PARKER 66PLP-10M-4G is a push-to-connect elbow tube fitting designed for fast, tool-free connections in pneumatic and fluid system plumbing. It accepts a 10mm outside diameter tube on one end and connects to a female BSPP threaded port on the other, making a 90-degree directional change in the line. Constructed from nickel-plated brass with a silicone-free grease lubricant, this fitting is rated to 300 psi maximum working pressure and handles temperatures from 0 degrees F to 200 degrees F. The yellow release button allows quick tube removal without tools. Licensed plumbers, pipefitters, and mechanical contractors install this fitting in compressed air, water, and compatible fluid lines.

This fitting is suited for residential and light commercial plumbing and pneumatic applications where a compact elbow connection between a metric tube and a female BSPP threaded port is required. The push-to-connect design speeds up installations and service calls compared to traditional compression or flare fittings. The nickel-plated brass body resists corrosion in typical indoor mechanical environments. Its UL94 V-0 flame resistance rating makes it appropriate for applications with relevant fire-resistance requirements.

Key Features

• Push-to-connect design allows tool-free tube insertion and release via yellow button
• Rated to 300 psi maximum working pressure
• Operating temperature range: 0 degrees F to 200 degrees F
• Nickel-plated brass body with silicone-free grease for broad fluid compatibility
• BSPP female thread type for compatibility with metric-standard ported equipment
• Meets UL94 V-0 flame resistance standard

Compatibility

Designed for use with 10mm outside diameter tubing and female BSPP threaded ports in pneumatic and fluid distribution systems. No specific equipment model compatibility was provided in the product data.

Installation Notes

Installation should be performed by a qualified plumber, pipefitter, or mechanical contractor familiar with BSPP threaded connections and push-to-connect pneumatic fittings. Depressurize and isolate the line completely before removing or installing any fitting. Ensure tubing is cut square and deburred before insertion into the push-to-connect port to prevent leaks and seal damage. Verify that the tube outside diameter and thread type of the mating port match the fitting specifications before installation.
