Parker 6105-24 Hydraulic Hose Fnpt Fitting 1-1/2 in 2500 Psi

Product Description

The PARKER 6105-24 is a straight female pipe rigid fitting designed for hydraulic hose assemblies operating at pressures up to 2,500 psi. Constructed from brass with a 1-1/2 inch FNPT threaded connection, it delivers a secure, leak-resistant joint in demanding fluid-power systems. The straight body configuration simplifies inline routing where direction changes are not required. With an overall length of 4.12 inches and a body diameter of 1-1/2 inches, this fitting is sized for larger-bore hose runs. It is rated for continuous service from -40 degrees F to 250 degrees F, making it suitable for both cold-start and elevated-temperature hydraulic circuits. Licensed hydraulic technicians and industrial mechanics install this fitting as part of hose fabrication or field repair work.

The PARKER 6105-24 is used in mobile and stationary hydraulic systems where a reliable FNPT rigid connection is required. Typical applications include dump trailers, engine test stands, oil field equipment, and submersible pump installations. The brass construction suits applications where corrosion resistance and compatibility with petroleum-based hydraulic fluids are priorities. It is part of the Parker 6100 series, a line of hydraulic hose fittings widely used across industrial and field-service environments.

Key Features

• Brass construction for corrosion resistance and compatibility with petroleum-based hydraulic fluids
• 2,500 psi maximum working pressure for high-demand hydraulic circuits
• 1-1/2 inch FNPT threaded connection for secure, leak-resistant assembly
• Straight body design for simplified inline hose routing
• Wide temperature range: -40 degrees F to 250 degrees F
• Overall length of 4.12 inches with 1-1/2 inch body diameter

Compatibility

Designed for use with dump trailers, engine test stands, oil field equipment, and submersible pump hydraulic hose assemblies. Part of the Parker 6100 series.

Installation Notes

Installation should be performed by a qualified hydraulic technician or industrial mechanic. Depressurize and lock out the hydraulic system completely before removing or installing any fittings. Clean all mating threads and inspect for damage before assembly. Apply thread sealant appropriate for hydraulic service per the system or component manufacturer guidelines.
