Parker 6.00F4MAU14A03.00 Rodless Air Cylinder 6 in Bore

Product Description

The PARKER 6.00F4MAU14A03.00 is a double acting rodless air cylinder built for industrial pneumatic motion control applications. It features a 6-inch bore and a 3-inch stroke, with a maximum working pressure rating of 250 psi. The body is constructed from aluminum, keeping weight manageable while maintaining structural integrity under cyclic load. The cylinder uses a 1-3/8-inch rod diameter with a 1-14 female thread style at the rod end and a 3/4 NPTF port for air supply connections. Licensed HVAC, industrial maintenance, and automation technicians install this type of cylinder in material handling, clamping, and actuated tooling setups.

This cylinder is suited for double acting pneumatic circuits where both extension and retraction are powered by compressed air. The side tapped mount configuration allows it to be secured directly to machine frames or fixture plates without external brackets. With an overall length of 9.625 inches and an overall width of 6.5 inches, it fits in moderate-envelope installations where a traditional rod-style cylinder would exceed available space. The M5 x 8 mount thread simplifies integration into metric-threaded mounting surfaces common in automated industrial equipment.

Key Features

• Double acting design: powered extension and retraction for positive control in both directions
• 6-inch bore diameter delivers high force output at standard shop air pressures
• 3-inch stroke length in a compact 9.625-inch overall length package
• Aluminum body reduces overall assembly weight without sacrificing rated pressure performance
• Nitrile butadiene rubber (NBR) seals provide reliable performance with standard lubricated or dry compressed air
• 3/4 NPTF port with side tapped mount and M5 x 8 thread for straightforward installation

Compatibility

Designed as an OEM-style replacement or direct-fit pneumatic actuator for industrial double acting rodless cylinder applications requiring a 6-inch bore, 3-inch stroke, and 3/4 NPTF porting with side tapped mounting.

Installation Notes

Installation should be performed by a qualified industrial mechanic or pneumatic systems technician. Depressurize and lock out the pneumatic supply line before removing any existing cylinder or making port connections. Verify port thread compatibility and use appropriate thread sealant rated for pneumatic service on the NPTF connections. Confirm that system supply pressure does not exceed the 250 psi maximum working pressure rating of this cylinder.
