Parker 50AT110CBPGN20H Hydraulic Filter Assembly 10 Micron

Product Description

The PARKER 50AT110CBPGN20H is a hydraulic filter assembly designed to remove contaminants from hydraulic fluid in industrial and mobile hydraulic systems. It uses a cellulose filter media rated at 10 microns, targeting particulate contamination that causes wear in pumps, valves, and actuators. The body is constructed from low carbon steel with an aluminum housing, and the port uses a 1-1/4 inch NPTF thread for secure, leak-resistant connection. The seal material is nitrile, compatible with common hydraulic fluids. This assembly is installed by hydraulic system technicians and fluid power specialists in both stationary and mobile equipment applications.

This filter assembly is suited for hydraulic circuits operating at pressures up to 150 psi and across a wide temperature range of -40 to 225 degrees F. It is a practical choice for return-line or low-pressure filtration applications in industrial machinery, construction equipment, and agricultural systems. The 1-1/4 inch NPT port size fits standard hydraulic plumbing configurations commonly found in these environments.

Key Features

• 10 micron cellulose media for particulate filtration in hydraulic circuits
• 1-1/4 inch NPTF threaded port for leak-resistant connection to standard NPT plumbing
• Low carbon steel and aluminum body construction for durability in industrial service
• Nitrile seal material compatible with petroleum-based hydraulic fluids
• Rated for operation from -40 to 225 degrees F across a wide service range
• Maximum operating pressure of 150 psi suitable for return-line and low-pressure circuits

Compatibility

Designed as an OEM-style replacement or direct-install hydraulic filter assembly for low-pressure and return-line hydraulic circuits using 1-1/4 inch NPT ported plumbing.

Installation Notes

Installation should be performed by a qualified hydraulic systems technician or fluid power mechanic. Depressurize and isolate the hydraulic circuit completely before removing or installing any filter components. Use appropriate thread sealant rated for hydraulic service on NPTF connections and avoid overtightening, which can damage the port or body. Verify flow direction and pressure ratings are within system specifications before returning the circuit to service.
