Parker 5 Sbu-s Bite-type Male Branch Tee 5/16in Od 1/8 Nptf

Product Description

The PARKER 5 SBU-S is a flareless bite-type tube fitting in a male branch tee configuration. It accepts tubing with a 5/16 inch outside diameter and connects to a threaded port via a 1/8 inch NPTF male thread. Bite-type fittings use a ferrule that bites into the tube wall on assembly, eliminating the need to flare the tube end. This design provides a secure, leak-resistant connection in hydraulic, pneumatic, and instrumentation lines. Licensed plumbers, HVAC technicians, and fluid-systems technicians install this type of fitting in both original equipment and field-repair applications.

This fitting is used wherever a branch takeoff is needed from a straight tube run with a male threaded port exit. Typical applications include compressed-air distribution, hydraulic control circuits, fuel lines, and instrumentation tubing runs in industrial and commercial equipment. The branch tee geometry allows one tube run to split into two directions while simultaneously providing a male threaded outlet, reducing the number of additional fittings required in a manifold or panel assembly.

Key Features

• Flareless bite-type design eliminates tube flaring during assembly
• Male branch tee configuration provides a simultaneous inline and threaded port connection
• 5/16 inch tube OD port sizing for standard instrumentation and hydraulic tubing
• 1/8 inch NPTF thread conforms to dryseal tapered thread standard for pressure-tight metal-to-metal sealing
• Compact, low-profile geometry suited to panel and manifold installations

Compatibility

Designed as an OEM-style and field-replacement bite-type tube fitting compatible with 5/16 inch OD tubing and 1/8 inch NPTF threaded ports in hydraulic, pneumatic, and instrumentation systems.

Installation Notes

Installation is performed by qualified technicians familiar with flareless tube fitting assembly procedures. De-pressurize and isolate the system completely before disassembling any existing fittings or inserting new ones. Follow the fitting manufacturer's assembly instructions for ferrule pre-swaging and final turn count, as under- or over-tightening a bite-type ferrule can compromise the seal. Verify NPTF thread engagement is adequate and inspect the assembled joint for leaks before returning the system to service.
