Parker 3J982-12-12 Female Seal-lok Swivel 90 Elbow 12mm

Product Description

The PARKER 3J982-12-12 is a female Seal-Lok swivel 90-degree elbow fitting designed for use in hydraulic hose assemblies. It accepts a 12 mm hose size and features a 1-3/16-12 SAE thread on the port end. The steel construction provides the strength and pressure resistance required in hydraulic circuits found on mobile equipment, industrial machinery, and fluid power systems. The swivel design allows the fitting to rotate during installation, reducing hose twist and simplifying routing in tight or angled plumbing configurations. Hydraulic technicians and fluid power specialists install this fitting when building or repairing hose assemblies that require a 90-degree change in flow direction.

This fitting is suited for hydraulic hose assemblies in both mobile and stationary applications where Seal-Lok face seal connections are specified. The Seal-Lok interface provides a leak-resistant metal-to-metal face seal, making it a common choice in high-pressure hydraulic circuits. The 90-degree elbow orientation helps route hoses around obstructions and reduces stress at connection points. A 3/4-inch body diameter accommodates standard hose end tooling for the 12 mm hose size. This fitting is installed by hydraulic technicians assembling or servicing fluid power circuits on agricultural, construction, or industrial equipment.

Key Features

• Female Seal-Lok face seal connection for leak-resistant high-pressure hydraulic service
• 90-degree swivel elbow design reduces hose twist and simplifies routing
• Compatible with 12 mm hydraulic hose size
• 1-3/16-12 SAE straight thread on the port end
• Steel construction for strength in demanding hydraulic applications
• 3/4-inch body diameter suits standard 12 mm hose end tooling

Compatibility

Designed as an OEM-style hydraulic hose fitting for fluid power assemblies requiring a 12 mm hose size with a 1-3/16-12 SAE Seal-Lok female swivel 90-degree elbow connection.

Installation Notes

Installation should be performed by a qualified hydraulic technician following applicable fluid power safety procedures. Depressurize and isolate the hydraulic circuit completely before removing or installing any fitting. Use the appropriate hose end swaging or crimping tooling specified for the 12 mm hose size and fitting series. Inspect the face seal surface and O-ring seating area for damage before assembly, and torque the swivel nut to the fitting manufacturer's recommended value for the thread size.
