Parker 3J982-10-10 Female Seal-lok Swivel 90 Deg Elbow

Product Description

The PARKER 3J982-10-10 is a female Seal-Lok swivel 90-degree elbow fitting designed for hydraulic hose assemblies. Constructed from steel, it provides a reliable, leak-resistant connection at angled routing points in high-pressure hydraulic systems. The Seal-Lok face-seal design eliminates the leak paths common with tapered-thread fittings, making it a preferred choice in mobile and industrial hydraulic applications. The 1-14 thread size and 10mm hose size designation make it a standard fit for medium-duty hydraulic circuits. Installation is performed by licensed hydraulic technicians and fluid power specialists working on equipment where reliable, vibration-resistant connections are critical.

This fitting is suited for use in mobile equipment, industrial machinery, and hydraulic power units where a 90-degree elbow transition is required at the hose termination point. The swivel feature allows the hose to be positioned without twisting during final assembly, reducing installation stress on the hose and fitting. Typical applications include agricultural equipment, construction machinery, and factory hydraulic systems where SAE Seal-Lok face-seal connections are specified.

Key Features

• Female Seal-Lok face-seal design provides a leak-resistant connection resistant to vibration loosening
• 90-degree swivel elbow allows hose routing in tight or angled spaces without inducing hose twist
• Steel construction for durability in high-pressure hydraulic service
• 1-14 thread size with SAE configuration for compatibility with standard hydraulic ports
• 10mm hose size suits medium-duty hydraulic circuit requirements
• 5/8 inch body diameter provides a compact profile for space-constrained installations

Compatibility

Designed as an OEM-style replacement or service fitting for hydraulic hose assemblies requiring a female Seal-Lok swivel 90-degree elbow with a 10mm hose size and 1-14 SAE thread configuration.

Installation Notes

Installation should be performed by a qualified fluid power technician or hydraulic specialist. Always depressurize and bleed the hydraulic system completely before removing or installing fittings. Inspect the face-seal O-ring for damage before assembly and replace if necessary. Torque to the fitting manufacturer specifications per SAE J1453 guidelines; do not over-tighten, as this can damage the face-seal surface.
