Parker 3C32F-F5 Hydraulic Check Valve 175 Gpm

Product Description

The PARKER 3C32F-F5 is a hydraulic control check valve designed to allow flow in one direction while preventing backflow in hydraulic systems. It features a 2-1/2-12 female NPTF inlet and a maximum flow rate of 175 GPM, making it suited for high-volume hydraulic circuits. The valve body measures 7.28 inches in overall length, 3.25 inches in overall width, and 7.28 inches in overall height. Fluorocarbon seals provide resistance to a wide range of hydraulic fluids and handle operating temperatures from -15 degrees F to 400 degrees F. This valve is installed by hydraulic system technicians and industrial mechanics working on mobile or stationary hydraulic equipment.

This check valve is applied in industrial and mobile hydraulic systems where directional control and backflow prevention are required. It is well suited for high-flow applications such as hydraulic power units, presses, lifts, and heavy equipment hydraulic circuits. The female NPTF thread standard ensures a pressure-tight mechanical seal without relying on thread sealant tape alone, which is important in high-pressure hydraulic plumbing. The fluorocarbon seal material makes it compatible with petroleum-based and many synthetic hydraulic fluids commonly used in demanding service environments.

Key Features

• Maximum flow rate of 175 GPM supports high-volume hydraulic circuit requirements
• 2-1/2-12 female NPTF inlet provides a leak-resistant threaded connection
• Fluorocarbon seals resist degradation from a broad range of hydraulic fluids
• Operating temperature range of -15 degrees F to 400 degrees F for demanding service conditions
• Compact envelope: 7.28 inches length, 3.25 inches width, 7.28 inches height

Compatibility

Designed as an OEM-style replacement or direct-install check valve for hydraulic systems with a 2-1/2-12 female NPTF port configuration and flow demands up to 175 GPM.

Installation Notes

Installation should be performed by a qualified hydraulic technician or industrial mechanic. Depressurize and de-energize the hydraulic system completely before removing any fittings or valves. Confirm port thread type and size before installation to avoid cross-threading or improper sealing. Inspect sealing surfaces and verify fluorocarbon seal condition before returning the system to service.
