Parker 3C24F-F5A Hydraulic Check Valve 125 Gpm 3000 Psi

Product Description

The PARKER 3C24F-F5A is a hydraulic control check valve designed to allow flow in one direction while preventing backflow in hydraulic systems. Built with a steel body and nitrile seals, it is rated for a maximum working pressure of 3000 psi and a maximum flow rate of 125 GPM. The inlet connection is a 1-1/2-inch, 11-1/2 thread Female NPTF fitting, making it compatible with standard threaded hydraulic plumbing. At 6.5 inches in overall length and 6.594 pounds, this is a robust inline valve suited for industrial and mobile hydraulic circuits. Hydraulic technicians and fluid power specialists are the primary installers.

This valve is used in hydraulic systems where preventing reverse flow is critical to circuit function or equipment protection. Typical applications include industrial machinery, mobile hydraulic equipment, and power unit assemblies where backflow could cause cylinder drift, pump damage, or loss of load control. The Female NPTF threaded inlet supports a reliable, leak-resistant connection in high-pressure hydraulic plumbing. Its compact footprint of 2.5 inches in width and 2.5 inches in height allows installation in tight equipment enclosures where space is limited.

Key Features

• 3000 psi maximum working pressure for high-pressure hydraulic circuit use
• 125 GPM maximum flow rate supports high-volume system demands
• 1-1/2-inch 11-1/2 Female NPTF threaded inlet for secure, leak-resistant connections
• Steel body construction for durability in demanding hydraulic environments
• Nitrile seals provide compatibility with common petroleum-based hydraulic fluids
• Compact overall dimensions minimize installation space requirements

Compatibility

Designed as an OEM-style replacement or direct-fit check valve for hydraulic systems requiring a 1-1/2-inch Female NPTF threaded connection rated to 3000 psi and 125 GPM.

Installation Notes

Installation should be performed by a qualified hydraulic technician or fluid power specialist. Fully depressurize and de-energize the hydraulic system before removing or installing any valve. Apply appropriate thread sealant to the NPTF threads in accordance with system fluid compatibility requirements. Follow applicable hydraulic system design standards and equipment manufacturer guidelines when integrating this valve into a circuit.
