Parker 3C24EF-EF5 Hydraulic Check Valve 125 Gpm 3000 Psi

Product Description

The PARKER 3C24EF-EF5 is a hydraulic control check valve rated for up to 125 GPM flow and a maximum working pressure of 3000 psi. Built with a steel body and fluorocarbon seals, it is designed for demanding hydraulic circuit applications where one-directional flow control and pressure retention are required. The inlet is a 1-7/8-12 female SAE thread. Overall dimensions are 6.5 inches in length, 2.5 inches in width, and 2.5 inches in height. This valve is installed by hydraulic system technicians and industrial mechanics working on mobile equipment, industrial machinery, or fluid power systems.

This valve fits into hydraulic circuits requiring controlled check function at elevated pressures. Typical applications include mobile hydraulic systems on construction and agricultural equipment, as well as industrial fluid power circuits. The female SAE thread inlet allows direct in-line installation with standard SAE hydraulic fittings. The fluorocarbon seal material provides resistance to a broad range of hydraulic fluids, including petroleum-based and synthetic formulations, making it suitable for varied operating environments.

Key Features

• Maximum flow rate of 125 GPM supports high-volume hydraulic circuits
• Rated to 3000 psi maximum working pressure for demanding pressure environments
• Steel body construction for durability in industrial and mobile applications
• Fluorocarbon seals offer compatibility with petroleum-based and synthetic hydraulic fluids
• 1-7/8-12 female SAE threaded inlet for standard in-line hydraulic plumbing
• Compact envelope at 6.5 inches length and 2.5 inches height and width

Compatibility

Designed for in-line installation in hydraulic systems using 1-7/8-12 female SAE threaded connections and operating within a 125 GPM and 3000 psi working envelope.

Installation Notes

Installation should be performed by a qualified hydraulic technician or fluid power specialist. Depressurize and bleed the hydraulic circuit completely before removing any existing valve or fitting. Verify that system pressure and flow ratings do not exceed the valve specifications before installation. Follow applicable fluid power safety standards and equipment manufacturer service procedures during installation and startup.
