Parker 36060600 Push-to-connect Union Straight Fitting

Product Description

The PARKER 36060600 is a push-to-connect union straight tube fitting designed for inline tube-to-tube connections in fluid and gas distribution systems. Constructed from nickel-plated brass, it accepts 6mm outside diameter tubing and holds a maximum working pressure of 435 psi. The push-to-connect design allows for fast, tool-free assembly, making it a practical choice for HVAC, pneumatic, and process plumbing technicians working in tight schedules or confined spaces. It is rated for both liquid and gas service and uses an FKM o-ring seal for reliable performance across a wide temperature range.

This fitting is suited for residential and light commercial applications where 6mm OD tubing is routed through refrigeration lines, pneumatic controls, or fluid transfer systems. Its straight union configuration makes it appropriate for extending or repairing tube runs without tools. Technicians working on systems requiring RoHS, REACH, ATEX, or FDA-compliant components will find this fitting meets those standards. Each package contains 5 fittings with a minimum order quantity of 1 package.

Key Features

• Push-to-connect design for fast, tool-free tube-to-tube inline connections
• Nickel-plated brass construction for corrosion resistance in fluid and gas service
• Rated to 435 psi maximum working pressure
• FKM o-ring seal compatible with a broad range of liquids and gases
• Operating temperature range of -13 degrees F to 302 degrees F
• Compliant with RoHS, REACH, ATEX, PED, ISO 14743, UL94 V-0, and FDA 21CFR standards

Compatibility

Designed for use with 6mm outside diameter tubing carrying liquid or gas media. Suitable for pneumatic, HVAC, refrigeration, and light process piping applications requiring a straight inline union connection.

Installation Notes

Installation is performed by a qualified plumbing, HVAC, or pneumatic systems technician. Shut off and depressurize the system fully before removing or installing any fitting. Ensure tubing ends are cut cleanly and squarely with no burrs before inserting into the push-to-connect collar. Verify that tubing outside diameter is exactly 6mm to achieve a proper seal.
