PARKER 3316-00 E35S190-HP Solenoid Valve Body

Product Description

The Parker Sporlan E-HP Series solenoid valve, model E35S190-HP (MPN: 3316-00), is built for high-pressure refrigeration systems. This valve body features a floating disc design that is effective in various applications, especially those using high-pressure refrigerants such as R410a and subcritical CO2. It also performs well in hot gas service. The synthetic-to-metal seat provides a reliable seal during operation.

• Robust floating disc design for challenging conditions.
• Compatible with CFC, HCFC, and HFC refrigerants.
• ODF copper connections ensure strong compatibility.

Product Highlights

This solenoid valve body is essential for reliable operation in demanding refrigeration systems.

Product Information

Standard Information

• Brand: Parker
• MPN: 3316-00

Technical Specifications

• Valve Type: E35S190-HP
• Connections ODF: 1-1/8 inches
• Port Size: 26 mm
• Flow Coefficient (Kv): 9.3 m³/h
• Minimum Pressure Differential: 0.07 bar
• Maximum Operating Pressure (MRP): 48.3 bar (700 psig)
• Maximum Fluid Temperature: 116°C (240°F)
• Maximum Ambient Temperature: 48.9°C
• Body Material: Brass
• Seat Material: Synthetic to Metal
• Compatible Coil Type: MKC-1E
