Parker 30682-6-6 Female Jic 37 Deg Swivel Elbow 3/8 in

Product Description

The PARKER 30682-6-6 is a female JIC 37-degree swivel elbow hydraulic hose fitting machined from steel. It is designed for use with hydraulic hose assemblies in fluid power systems that require a leak-resistant, angled threaded connection. The fitting accepts a 3/8 inch (9.50 mm) inside diameter hose and uses a 9/16-18 thread size. At 1.75 inches overall length, it provides a compact profile suited for tight routing applications. Installation is performed by licensed hydraulic technicians and qualified fluid power mechanics working on mobile or stationary hydraulic equipment.

This fitting is used in hydraulic hose assemblies where a directional change at the hose end is required without bending the hose itself. The swivel design allows the fitting to rotate during assembly, reducing torsional stress on the hose. It is appropriate for industrial, agricultural, mobile, and construction hydraulic circuits. Parker Series 82 specifies this fitting for use with Parker 801, 804, 821, 821FR, and 836 hoses, making it a direct-fit component in those hose assembly configurations.

Key Features

• Female JIC 37-degree flare swivel elbow provides a reliable, vibration-resistant hydraulic connection
• Swivel design reduces hose twist during assembly and routing
• Steel construction for durability in demanding hydraulic service environments
• 9/16-18 thread size with threaded connection type for standard JIC compatibility
• 3/8 inch hose inside diameter fits Parker 801, 804, 821, 821FR, and 836 hoses
• Compact 1.75 inch overall length suits space-constrained plumbing layouts

Compatibility

Designed for use with Parker 801, 804, 821, 821FR, and 836 hoses. Part of Parker Series 82 hydraulic hose fittings.

Installation Notes

Installation should be performed by a qualified hydraulic technician or fluid power mechanic. Depressurize and isolate the hydraulic circuit completely before removing or installing any fittings. Inspect mating threads and seating surfaces for damage before assembly. Follow the hose and fitting manufacturer assembly guidelines for proper torque and swivel orientation to avoid system leaks.
