Parker 3.00NLP93.00 Rodless Air Cylinder 3 in Bore 250 Psi

Product Description

The PARKER 3.00NLP93.00 is a double acting rodless air cylinder designed for linear motion control in pneumatic systems. With a 3-inch bore and 3-inch stroke, it delivers reliable bidirectional actuation powered by compressed air. The cylinder body is constructed from aluminum with steel components, keeping weight low while maintaining structural integrity under pressure. A 1/4 NPT port accepts standard pneumatic fittings for quick integration into existing air lines. Rated to 250 psi maximum working pressure, this cylinder suits demanding industrial and mechanical applications. Licensed HVAC technicians, pipefitters, and mechanical contractors typically specify this style of cylinder for automation, positioning, and actuator tasks.

This cylinder is suited for use in pneumatic automation systems, material handling equipment, and mechanical actuation assemblies where a compact, rodless design is required. The head or cap mounting style gives installers flexibility in how the unit is oriented and fastened within a machine frame or panel. The 4.25-inch overall width fits within tight enclosures and retrofit installations. Nitrile butadiene rubber seals provide resistance to standard industrial lubricants and fluids commonly present in compressed-air systems.

Key Features

• Double acting design provides powered extension and retraction for precise bidirectional control
• 3-inch bore with 3-inch stroke delivers consistent linear force output across the full travel range
• 250 psi maximum working pressure rating supports high-demand pneumatic circuits
• Aluminum body construction reduces overall assembly weight while maintaining durability
• 1/4 NPT port accepts standard pneumatic fittings without adapters in most applications
• Nitrile butadiene rubber seals offer compatibility with common industrial compressor oils and air-line lubricants

Compatibility

Designed as an OEM-style replacement or direct-fit component for pneumatic actuation systems requiring a double acting rodless cylinder with a 3-inch bore and 1/4 NPT porting.

Installation Notes

Installation should be performed by a qualified mechanical or pneumatic technician. Depressurize the air supply and lock out the compressed-air source before mounting or removing the cylinder. Ensure port fittings are rated to at least the system maximum working pressure and that all threads are sealed with appropriate thread sealant rated for pneumatic service. Verify that the mounting surface and fasteners can accommodate the cylinder load and any side forces generated during actuation.
