Parker 3.00NLP92.00 Rodless Air Cylinder 3in Bore 250 Psi

Product Description

The PARKER 3.00NLP92.00 is a double acting rodless air cylinder designed for industrial pneumatic systems where compact linear motion is required. With a 3 inch bore and 2 inch stroke, this cylinder delivers controlled bidirectional actuation using compressed air. Maximum working pressure is 250 psi. The body is constructed from aluminum with steel components, keeping weight low while maintaining structural integrity. A nitrile butadiene rubber (NBR) seal package provides reliable air retention across a wide range of operating temperatures. Licensed HVAC, plumbing, and industrial mechanical technicians working on pneumatic automation, process equipment, or production machinery will encounter this style of cylinder in field service and replacement work.

This cylinder is suited for pneumatic automation applications in both light industrial and production environments. Its rodless design makes it a practical choice where a standard rod-style cylinder would create clearance or length constraints in the machine envelope. The 1/4 NPT port allows direct connection to standard pneumatic fittings and manifold assemblies. Head or cap mounting options give installers flexibility when integrating into existing frameworks or custom fabricated brackets. Overall width is 4.25 inches, supporting straightforward space planning during design or replacement.

Key Features

• Double acting design allows powered extension and retraction via compressed air
• 3 inch bore with 2 inch stroke for compact, controlled linear motion
• 250 psi maximum working pressure for standard industrial pneumatic circuits
• 1/4 NPT port size for compatibility with common pneumatic fittings and tubing
• Aluminum body construction reduces overall assembly weight
• NBR seal material resists wear and maintains air integrity under typical industrial conditions
• Head or cap mount options provide installation flexibility

Compatibility

Designed as an OEM-style replacement or direct-fit component for industrial pneumatic systems requiring a double acting rodless cylinder with a 3 inch bore and 2 inch stroke at 250 psi working pressure.

Installation Notes

Installation of pneumatic cylinders should be performed by qualified industrial mechanics or pneumatic system technicians. Depressurize and lock out the pneumatic circuit before removing the existing cylinder or connecting new air lines. Verify port thread engagement using appropriate NPT fittings and thread sealant rated for compressed air service. Do not exceed the 250 psi maximum working pressure rating during system commissioning or testing.
