Parker 2F-C2L-1-SS Check Valve 1/8 Inch Fnpt Stainless Steel

Product Description

The PARKER 2F-C2L-1-SS is a stainless steel inline check valve designed to allow one-directional fluid or gas flow while preventing backflow in piping systems. Built with a 1/8 inch pipe size and female NPT connections on both ends, this valve is rated to 6,000 WOG (Water, Oil, Gas), making it suited for high-pressure service applications. Both the body and spring are constructed from stainless steel, providing corrosion resistance in demanding environments. Licensed plumbers, pipefitters, and industrial maintenance technicians are the typical installers for valves in this class.

This check valve is intended for inline installation in small-bore piping systems where backflow prevention is required. The 1/8 inch FNPT x FNPT configuration fits standard pipe thread connections commonly found in instrumentation lines, compressed air systems, hydraulic circuits, and fluid transfer applications. Its compact size and stainless steel construction make it appropriate for corrosive media, high-pressure service, and installations where system integrity must be maintained across a range of temperatures and pressures.

Key Features

• 6,000 WOG pressure rating for high-pressure fluid and gas service
• Stainless steel body and spring for corrosion resistance and long service life
• 1/8 inch FNPT x FNPT end connections for straightforward inline installation
• Inline valve design allows direct insertion into existing piping runs
• Suitable for water, oil, and gas service as indicated by WOG rating

Compatibility

Designed as an OEM-style replacement or new-installation check valve for 1/8 inch FNPT piping systems requiring backflow prevention in high-pressure service.

Installation Notes

Installation should be performed by a licensed plumber or qualified pipefitter in accordance with applicable plumbing codes such as the IPC or IFGC. Isolate and depressurize the system fully before removing any existing valve or fitting. Apply thread sealant compatible with the service media to the male NPT threads before making up connections. Verify flow direction markings on the valve body before final installation to ensure correct orientation.
