Parker 24X24X1 Pleated Panel Air Filter Merv 8 1200 Cfm

Product Description

The PARKER 24X24X1 is a self-supported pleated panel air filter rated MERV 8, designed for industrial and commercial HVAC air handling systems. Built on a synthetic media platform with a one-piece heavy-duty beverage board frame, this filter delivers a 1200 CFM flow rate at 300 FPM with an initial resistance of only 0.15 inches WG. The self-supported pleat construction eliminates the need for a wire backing, keeping pressure drop low while maintaining a 7 square foot media area. HVAC technicians and facilities maintenance professionals install this filter in ducted air handling units where reliable particulate capture and extended service intervals are required.

This filter is suited for commercial and industrial air handling applications where MERV 8 efficiency is specified. Nominal dimensions are 24 inches wide by 24 inches tall by 1 inch deep, with actual dimensions of 23-3/8 inches by 23-3/8 inches by 3/4 inch. The synthetic media handles operating temperatures up to 150 degrees F, making it appropriate for a wide range of commercial rooftop units, air handlers, and inline duct filter housings found in light industrial and institutional settings.

Key Features

• MERV 8 mechanical efficiency per ASHRAE 52.2
• 1200 CFM rated flow at 300 FPM with 0.15 inches WG initial resistance
• Self-supported pleated construction with no wire backing required
• 7 square foot synthetic media area for high dust holding capacity
• One-piece die-cut heavy-duty beverage board frame
• UL 900 listed and tested to UL Canada and US standards

Compatibility

Designed as a MERV 8 OEM-style replacement panel filter for commercial and industrial air handling units, rooftop units, and ducted filter housings accepting a nominal 24 x 24 x 1 inch filter.

Installation Notes

Installation is typically performed by licensed HVAC technicians or qualified facilities maintenance personnel. Always shut down the air handling unit and lock out power before servicing the filter section. Verify the actual filter bay dimensions match the 23-3/8 inch by 23-3/8 inch by 3/4 inch actual size before installation. Install with airflow arrow pointing in the direction of system airflow, and inspect the frame seal against the filter rack to prevent bypass.

Technical Specifications

• Nominal Size: 24 x 24 x 1 inches
• Actual Width: 23-3/8 inches
• Actual Height: 23-3/8 inches
• Actual Depth: 3/4 inch
• MERV Rating: 8
• Flow Rate: 1200 CFM at 300 FPM
• Initial Resistance: 0.15 inches WG
• Final Resistance: 1 inch WG
• Media Type: Synthetic
• Media Area: 7 square feet
• Filter Type: Self-Supported Pleated Panel
• Frame Construction: One-Piece, Heavy Duty, Die Cut, Beverage Board
• Temperature Rating: 150 degrees F
• Application: Industrial, Commercial
• Standards: ASHRAE 52.2, UL 900, UL Canada and US

Standard Information

• Brand: PARKER
• Manufacturer Part Number: 24X24X1
