Parker 24M-8-8 Hydraulic Manifold 2 Inlet 4 Outlet Ports

Product Description

The PARKER 24M-8-8 is a multi-port hydraulic manifold designed to distribute or collect fluid flow across multiple circuits in a single compact assembly. It features 2 inlet ports and 4 outlet ports, both sized at 1/2 inch, with NPTF threaded connections and a glass filled nylon body reinforced with brass internal hardware. The manifold handles a maximum working pressure of 150 psi and operates across a temperature range of -40 degrees F to 200 degrees F. At 6.49 inches in overall length and 1.02 inches in width, it fits into tight plumbing or fluid distribution assemblies. Licensed plumbers, HVAC technicians, and fluid system installers work with this component in both mobile and stationary fluid handling systems.

The PARKER 24M-8-8 is suited for residential and light commercial fluid distribution applications where multiple branch lines must be fed from a common supply. Its six total ports and 1.1 inch outlet center-to-center spacing make it practical for close-quarter manifold installations. The part meets D.O.T. FMVSS571.106, SAE J1131, and SAE J2494-3 standards, making it appropriate for systems where compliance with automotive or fluid conveyance specifications is required. It is commonly installed in hydronic, fuel, or brake line distribution assemblies.

Key Features

• 2 inlet ports and 4 outlet ports, all 1/2 inch NPTF threaded
• Glass filled nylon body with brass material components for durability and corrosion resistance
• 150 psi maximum working pressure rating
• Operating temperature range of -40 degrees F to 200 degrees F
• 1.1 inch outlet center-to-center spacing for compact installation
• Meets D.O.T. FMVSS571.106, SAE J1131, and SAE J2494-3 standards

Compatibility

Designed as an OEM-style replacement or direct-fit manifold component for fluid distribution systems requiring 1/2 inch NPTF connections with 2 inlet and 4 outlet ports.

Installation Notes

Installation should be performed by a licensed plumber or qualified fluid systems technician. Depressurize and drain the system fully before removing any existing manifold or fittings. Use thread sealant rated for the fluid type and pressure range when making NPTF connections. Verify port alignment and support the manifold body to avoid stress on the fittings after installation.
