Parker 249IFHD-4-4 Male Elbow 249IFHD-249IF

Product Description

The Parker 249IFHD-4-4 is a brass male elbow fitting designed for fluid connection. This fitting features a forty-five degree inverted flare, compliant with SAE J512 standards. It's suitable for use with various types of tubing like copper, brass, aluminum, and steel that can be flared.

• Material: Brass
• Operating Temperature: -65°F to +250°F
• Pressure Rating: 1400 PSI

Product Highlights

This product supports reliable connections in fluid systems, ensuring safe and effective performance in various environments.

Product Information

Standard Information

• Manufacturer: Parker
• Min Order Qty: 1

Technical Specifications

• Outer Diameter 1: 1/4 Inch
• Thread 1: 7/16-24 UN/UNF
• Thread 2: 1/4 NPT
• Material: Brass
• Series: 45° Inverted Flare
• Configuration Type: Flare to Male
• Configuration Sub-Type: Male Elbow 90°
• Body Shape: Extruded
• Thread 1 Type: UN/UNF
• Thread 2 Type: NPT
• SAE Compliance: J512
• Operating Temperature: -65°F to +250°F
• Pressure Rating: 1400 PSI
