Parker 207P-12 Pipe Coupling 3/4 Inch Fnptf 1000 Psi

Product Description

The PARKER 207P-12 is an industrial pipe coupling designed for high-pressure fluid and pneumatic systems. It features a 3/4-inch Female National Pipe Thread Fuel (FNPTF) connection on both ends, allowing two threaded pipe sections to be joined in a straight-line configuration. Rated to 1,000 psi maximum working pressure, this coupling handles demanding service conditions across a wide temperature range of -65 degrees F to 250 degrees F. It meets SAE J530 and SAE J531 standards. Licensed plumbers, pipefitters, and industrial maintenance technicians are the typical installers for this type of fitting.

This coupling is suited for residential, commercial, and industrial piping applications where a reliable FNPTF threaded connection is required. Typical use cases include hydraulic lines, pneumatic distribution systems, fuel supply lines, and general industrial fluid transfer. The 3/4-inch thread size is a common pipe size in both building mechanical systems and equipment hookups. Its broad temperature range makes it appropriate for both cold-service and moderate heat applications.

Key Features

• 3/4-inch FNPTF female thread connection on both ends for straight pipe joining
• 1,000 psi maximum working pressure rating for high-pressure service
• Wide service temperature range: -65 degrees F to 250 degrees F
• Meets SAE J530 and SAE J531 standards
• Compact design at 0.36 pounds for easy handling and installation

Compatibility

Designed as an OEM-style replacement or new-installation fitting for industrial and commercial piping systems requiring a 3/4-inch FNPTF threaded pipe coupling rated to 1,000 psi.

Installation Notes

Installation should be performed by a licensed plumber or qualified pipefitter in accordance with applicable codes such as the IPC or IFGC. Depressurize and isolate the line completely before removing any existing fittings or making new connections. Apply appropriate thread sealant or PTFE tape to the male threads mating to this coupling per the system fluid compatibility requirements. Do not exceed the rated working pressure or temperature limits of the fitting.
