Parker 2.50TEF4MAU14A05.00 Rodless Air Cylinder 2.5in 250psi

Product Description

The PARKER 2.50TEF4MAU14A05.00 is a double acting rodless air cylinder engineered for linear motion applications in industrial pneumatic systems. Built with an aluminum body, it features a 2.5-inch bore and a 5-inch stroke, providing a compact yet capable actuator for space-constrained installations. The cylinder operates at up to 250 psi and uses a 3/8 NPTF port for reliable air connections. Nitrile butadiene rubber (NBR) seals deliver durable performance across a range of operating conditions. Licensed HVAC, automation, and mechanical system technicians install this type of actuator in production and process equipment.

This rodless cylinder is suited for light-to-medium duty industrial automation, material handling, and positioning applications where a traditional rod-style cylinder would require excessive clearance. The basic mount configuration allows direct attachment to machine frames or fixture plates. With an overall length of 8.75 inches and an overall width of 3 inches, it fits into tight linear actuator envelopes. The 7/16-20 female rod thread size accommodates standard coupling hardware for load attachment.

Key Features

• Double acting design provides powered motion in both extend and retract directions
• 2.5-inch bore and 5-inch stroke deliver controlled linear force output up to 250 psi
• Aluminum body construction reduces overall system weight
• NBR seals provide resistance to typical pneumatic system fluids and lubricants
• 3/8 NPTF port integrates with standard compressed air plumbing
• Basic mount style simplifies direct attachment to machine structures

Compatibility

Designed as an OEM-style replacement or direct-fit component for industrial pneumatic linear motion systems requiring a double acting rodless cylinder with a 2.5-inch bore and basic mount configuration.

Installation Notes

Installation should be performed by a qualified industrial mechanic or pneumatic systems technician. Depressurize and lock out the air supply before removing or installing any cylinder. Verify that all port fittings and thread sealants are compatible with the operating pressure before returning the system to service. Follow applicable OSHA lockout/tagout procedures and the equipment manufacturer guidelines throughout installation.
