Parker 2.00DXPSRM12.00 Rodless Air Cylinder 2 in 12 in

Product Description

The PARKER 2.00DXPSRM12.00 is a double acting rodless air cylinder engineered for industrial pneumatic motion control applications. With a 2-inch bore and a 12-inch stroke, it delivers linear actuation without an exposed rod, making it well suited for space-constrained installations. Operating at up to 250 psi maximum working pressure, the cylinder body is constructed from stainless steel for durability in demanding environments. Port connections are 1/4 NPTF. The unit weighs 2.8 pounds and measures 2.08 inches in overall width and 19.22 inches in length. Installation is handled by licensed millwrights, pneumatic system technicians, or industrial maintenance professionals.

This cylinder is designed for use in factory automation, material handling, and general industrial pneumatic systems where a rodless design reduces footprint and protects the actuator mechanism from side loading. The double end or rear pivot mounting style provides flexible positioning within a machine frame or linear slide assembly. The 1/4 NPTF port accommodates standard compressed air supply lines common in industrial facilities.

Key Features

• Double acting design provides powered motion in both extension and retraction directions
• Rodless configuration eliminates external rod exposure, reducing overall installation length requirements
• Stainless steel body construction for corrosion resistance in wash-down or harsh industrial environments
• 250 psi maximum working pressure rating supports demanding pneumatic circuits
• 1/4 NPTF port type ensures leak-resistant threaded connections to air supply fittings
• Double end or rear pivot mounting style allows multiple positioning orientations

Compatibility

Designed as an OEM-style replacement or direct-fit component for industrial pneumatic systems requiring a double acting rodless cylinder with a 2-inch bore and 12-inch stroke at 250 psi maximum working pressure.

Installation Notes

Installation should be performed by a qualified pneumatic systems technician or licensed millwright. Depressurize and lock out the compressed air supply before removing or installing any cylinder. Verify that supply line pressure does not exceed the 250 psi maximum working pressure rating before commissioning. Confirm port fitting compatibility with the 1/4 NPTF thread specification prior to assembly.
