Parker 1JC56-8-6 Female Seal-lok Swivel Fitting 6000 Psi

Product Description

The PARKER 1JC56-8-6 is a female Seal-Lok swivel short fitting designed for hydraulic hose assemblies operating at pressures up to 6,000 psi. Constructed from steel, it features a 13/16-16 thread size and accommodates a 3/8-inch hose diameter. The swivel design allows rotation during assembly, reducing hose twist and making installation in tight or confined plumbing runs more manageable. The Seal-Lok face-seal configuration provides a leak-resistant connection well suited to high-pressure hydraulic circuits. This fitting is installed by hydraulic system technicians and industrial maintenance professionals working on mobile or stationary hydraulic equipment.

This fitting is intended for use in hydraulic hose assemblies where a female Seal-Lok face-seal termination is required. With a 1-inch body diameter and 13/16-16 thread, it is a common choice for medium-bore hydraulic lines in industrial, agricultural, and mobile equipment applications. The short-body configuration suits installations where space is limited and a compact fitting profile is needed.

Key Features

• 6,000 psi pressure rating for high-pressure hydraulic circuits
• Female Seal-Lok face-seal interface minimizes leak paths at the connection point
• Swivel design reduces hose twist during assembly and routing
• Steel construction provides durability in demanding hydraulic environments
• Short-body design suits confined installation spaces
• 13/16 hex size compatible with standard hydraulic wrenching tools

Compatibility

Designed as an OEM-style replacement or new-build component for hydraulic hose assemblies requiring a female Seal-Lok swivel short fitting with a 13/16-16 thread and 3/8-inch hose size.

Installation Notes

Installation should be performed by a qualified hydraulic technician. Depressurize and isolate the hydraulic circuit completely before disassembling any fittings or hose ends. Torque the fitting to the hydraulic system manufacturer's specifications using the appropriate crowfoot or open-end wrench on the 13/16 hex. Inspect the face-seal surface and O-ring for damage before assembly, as a compromised seal will result in leakage under pressure.
