Parker 170PTCNS-6-2 Push-to-connect Tube Fitting Brass

Product Description

The PARKER 170PTCNS-6-2 is a brass push-to-connect tube fitting with a female NPT center port, designed for inline tube-to-tube connections with a threaded branch outlet. It accepts 3/8 inch OD tubing on both push-to-connect ends and features a 1/8 inch NPTF female thread. Rated to 250 psi, this fitting is constructed from brass with a nitrile O-ring seal and is compliant with D.O.T. FMVSS571.106, SAE J2494, and SAE J2494-3 standards. It is a general-purpose fitting suited for pneumatic and fluid line assemblies across HVAC, refrigeration, and related trade applications.

This fitting is used in residential and light commercial applications where a push-to-connect tube run must also branch off to a female-threaded port. Typical install scenarios include air lines, control tubing, and fluid transfer systems where fast, tool-free tube connections are required alongside an NPT-threaded component tie-in. The operating temperature range of -40 degrees F to 200 degrees F makes it suitable for a broad range of ambient and fluid conditions encountered in trade service work.

Key Features

• Push-to-connect design on both tube ends allows fast, tool-free tube insertion for 3/8 inch OD tubing
• 1/8 inch NPTF female center thread provides a secure, pressure-rated threaded connection point
• Brass body with nitrile O-ring seal for durability and compatibility with general-purpose fluids and gases
• Rated to 250 psi working pressure
• Meets D.O.T. FMVSS571.106, SAE J2494, and SAE J2494-3 specifications
• Wide temperature range: -40 degrees F to 200 degrees F

Compatibility

Designed for use with 3/8 inch OD tubing in general-purpose pneumatic and fluid line systems requiring a female NPT branch connection. Suitable for applications conforming to D.O.T. FMVSS571.106, SAE J2494, and SAE J2494-3 standards.

Installation Notes

Installation is typically performed by licensed HVAC technicians, plumbers, or pipefitters. De-energize and depressurize the system fully before removing or installing any fittings. Ensure tubing is cut cleanly and squarely with no burrs before inserting into the push-to-connect end. Verify that the NPTF thread engagement meets applicable IPC or IFGC requirements for the service application.

WARNING: This product can expose you to chemicals including lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
