Parker 16F24C6164AAF 2-way Solenoid Valve 1 Inch Npt

Product Description

The PARKER 16F24C6164AAF is a two-way piloted diaphragm solenoid valve designed for controlling the flow of fluids, gases, and light oils in industrial piping systems. The valve features a 1-inch NPT port, stainless steel body, and NBR seal construction, making it suitable for demanding service environments. It operates in a normally closed (NC) state and accepts multiple coil voltage options including 12 Vdc, 24 Vdc, 24/60 Vac, 120 Vdc, 120/60 to 110/50 Vac, and 240/60 to 220/50 Vac. With a Cv factor of 13.0 and a maximum working pressure of 150 psi, this valve delivers reliable on/off flow control. Installation and service are typically performed by licensed plumbers, pipefitters, or industrial maintenance technicians.

This valve is well suited for residential, commercial, and light industrial process piping applications where automated flow shutoff or control is required. Typical installations include water treatment systems, compressed air lines, fuel gas service, and light oil distribution. The piloted diaphragm design requires a minimum operating pressure differential of 5 psi to function correctly, so it is best applied in systems with adequate line pressure. Maximum fluid temperature is 180 degrees F. The CSA Certified, UL Listed, and NEMA 4X ratings make it appropriate for wet and washdown environments.

Key Features

• Two-way piloted diaphragm design in normally closed (NC) configuration
• 1-inch NPT port with stainless steel body for corrosion-resistant service
• NBR seal material compatible with fluids, gases, and light oils
• Multi-voltage coil compatibility: 12 Vdc, 24 Vdc, 24/60 Vac, 120 Vdc, 120/60 to 110/50 Vac, 240/60 to 220/50 Vac
• Cv rating of 13.0 and maximum working pressure of 150 psi
• CSA Certified, UL Listed, and NEMA 4X rated for broad application compliance

Compatibility

Designed as an OEM-style two-way solenoid valve for industrial and commercial piping systems requiring 1-inch NPT normally closed flow control. Cross-references ASCO Number 8210G89. Note that solenoid coils are sold separately and are not included with this valve body.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable local and national plumbing codes. Shut off and depressurize the line completely before removing or installing the valve. Verify that the system operating pressure differential meets the 5 psi minimum required for proper piloted diaphragm actuation. Select the correct coil voltage to match the control circuit before energizing the valve.
