Parker 15F22EA Coalescing Filter 34 Cfm 3/8 Inch Port

Product Description

The PARKER 15F22EA is a coalescing filter designed to remove oil aerosols, water mist, and fine particulates from compressed air lines. With a 0.01 micron rating, it delivers high-efficiency filtration suitable for sensitive pneumatic instrumentation, spray finishing equipment, and process air applications. The unit features a polycarbonate bowl with manual drain and modular connection for inline installation in compressed air distribution systems. It handles flow rates up to 34 CFM at a maximum working pressure of 150 psi. Typical installers are industrial maintenance technicians and pipefitters working on compressed air system design or service.

The 15F22EA is suited for both light industrial and commercial compressed air systems where downstream equipment requires clean, dry air. The 3/8 inch port size fits standard fractional compressed air piping. The modular connection style allows pairing with compatible Parker filter-regulator-lubricator components for a full air preparation assembly. The polycarbonate bowl provides visual monitoring of condensate accumulation between manual drain intervals. This filter is appropriate for residential workshop setups and commercial production environments alike.

Key Features

• 0.01 micron filtration rating removes fine oil aerosols and water mist from compressed air
• 34 CFM flow capacity supports a range of pneumatic tool and instrument applications
• 150 psi maximum working pressure for compatibility with standard compressed air systems
• Polycarbonate bowl allows visual inspection of condensate level without disassembly
• Manual drain for controlled condensate removal during maintenance intervals
• Modular connection enables inline assembly with Parker filter-regulator-lubricator components

Compatibility

Designed as an OEM-style replacement or new-installation coalescing filter for compressed air preparation systems using 3/8 inch port connections and modular inline assembly configurations.

Installation Notes

Installation is performed by qualified industrial maintenance technicians or pipefitters. De-pressurize and lock out the compressed air supply line before removing or installing any filter component. Ensure flow direction marked on the filter body matches the direction of air flow in the system. Verify all fittings and connections are properly seated and leak-tested after installation before returning the system to service.
