Parker 155F-5 Union Elbow 155F 45 Degree Flare (5/16 Inch) Replacement MPN

Product Description

The Parker 155F-5 Union Elbow provides a reliable connection in piping systems. This fitting adheres to SAE J512 and J513 specifications and is suitable for use with copper, brass, aluminum, or steel tubing capable of being flared at a forty-five degree angle.

• Meets SAE J512 and J513 standards.
• Compatible with various tubing materials.
• Operating temperature range of -65°F to +250°F.

Product Highlights

Designed for seamless transitions in plumbing and HVAC applications.

Product Information

Standard Information

• Manufacturer: Parker
• Part Number: 155F-5

Technical Specifications

• Material: Brass
• Pressure Rating: 1200 PSI
• Configuration Type: Flare to Flare
• Configuration Sub-Type: Union Elbow 90°
• Outer Diameter 1: 5/16 Inch
• Outer Diameter 2: 5/16 Inch
• Thread 1: 1/2-20 UN/UNF
• Thread 2: 1/2-20 UN/UNF
• Inch/Metric: Inch
• Operating Temperature: -65°F to +250°F
• Parker Division: Fluid Systems Connector (Brass Products)
• Parker Group: Fluid Connector
• SAE Compliance: J512 and J513
• SAE Reference: SAE 010201
• Body Shape: Forged
