Parker 149F-5-6 Male Elbow 45 Degree Flare 5/16 Inch Replacement MPN

Product Description

The Parker 149F-5-6 Male Elbow is designed for 45 degree flare applications. It meets the standards set by SAE J512 and J513. This fitting is suitable for use with copper, brass, aluminum, or steel tubing that can be flared at a 45 degree angle.

• Meets SAE compliance standards J512 and J513
• Operating temperature range from -65 degrees Fahrenheit to +250 degrees Fahrenheit
• Pressure rating of 1200 PSI

Product Highlights

This brass fitting is robust and designed for a range of piping needs. It provides reliable connections in various plumbing applications.

Product Information

Standard Information

• Manufacturer: Parker
• Minimum Order Quantity: 1

Technical Specifications

• Outer Diameter 1: 5/16 Inch
• Thread 1: 1/2-20 UN/UNF
• Thread 2: 3/8 NPT
• Material: Brass
• Series: 45 Degree Flare
• Configuration Type: Flare to Male
• Configuration Sub-Type: Male Elbow 90 Degree
• Operating Temperature: -65 degrees Fahrenheit to +250 degrees Fahrenheit
