Parker 149F-10-12 Male Elbow 149F-249F 45 Degree Flare

Product Description

The Parker Male Elbow 149F-249F, MPN 149F-10-12, is a reliable option for connecting tubing at a 45-degree angle. These fittings meet the requirements of SAE J512 and J513. They are safe for use with various types of tubing including copper, brass, aluminum, and steel.

• Designed for a 45-degree connection
• Suitable for different types of metal tubing
• Meets SAE J512 and J513 standards

Product Highlights

This elbow fitting is designed for durability and efficiency in plumbing and HVAC applications.

Product Information

Standard Information

• Manufacturer: Parker
• Part Number: 149F-10-12

Technical Specifications

• Outer Diameter 1: 5/8 Inch
• Thread 1: 7/8-14 UN/UNF
• Thread 2: 3/4 NPT
• Material: Brass
• Series: 45 Degree Flare
• Configuration Type: Flare to Male
• Configuration Sub-Type: Male Elbow 90 Degree
• Operating Temperature: -65°F to +250°F
• Parker Division: Fluid Systems Connector (Brass Products)
• Pressure Rating: 650 PSI
