Parker 13743-8-8 Hydraulic Hose Female Swivel 45 Elbow

Product Description

The PARKER 13743-8-8 is a female swivel 45-degree elbow hydraulic hose fitting designed for use in high-pressure hydraulic fluid conveyance systems. Manufactured from steel, this Series 43 fitting connects to hoses with a 0.5-inch (size 8) inside diameter using a female JIC threaded interface. The 45-degree elbow geometry allows routing in tight spaces where straight or 90-degree fittings cannot clear adjacent components. Installation is handled by hydraulic system technicians and fluid power mechanics working on mobile equipment, industrial machinery, and stationary hydraulic power units.

This fitting is suited for both industrial and mobile hydraulic applications where a swivel-style female JIC connection is required at a 45-degree angle. The swivel feature allows the hose to be torqued onto the fitting body without twisting the hose assembly itself, reducing stress on the hose during installation and service. Thread size is 1/2 inch. Compatible hose series are listed in the specifications below.

Key Features

• Female swivel 45-degree elbow geometry for angled hose routing in confined installations
• Female JIC threaded connection type for secure, leak-resistant sealing
• Steel construction for durability in hydraulic fluid service
• Size 8 fitting with 0.5-inch inside diameter for proper flow match to hose bore
• Swivel design allows hose installation without introducing torsional stress
• Meets ISO 12151-5 standard; compliant with California Proposition 65 requirements

Compatibility

Designed for use with the following Parker hose series: 187 TC, 187 ST, 302, 304, 387 TC, 387 ST, 422, 424, 426, 436, 471TC, 471ST, 472TC, 482TC, 482ST, 487 TC, 487 ST, 722 TC, 722 ST, 787 TC, 787 ST, 797 TC, 797 ST, and 881 hoses.

Installation Notes

Hydraulic fittings should be installed by a qualified fluid power technician or hydraulic system mechanic. Before servicing any hydraulic line, fully depressurize the system and confirm zero residual pressure using an appropriate gauge. Use a backup wrench on the fitting body when tightening to prevent rotation and avoid damaging the swivel seat. Follow applicable IFGC and equipment OEM torque and assembly guidelines for JIC threaded connections.
