Parker 12F32HC Coalescing Filter 135 Cfm 1/2 Inch Port

Product Description

The PARKER 12F32HC is a coalescing filter designed to remove oil aerosols, liquid water, and fine particulate from compressed air lines. It features a 1/2 inch port and a rated flow capacity of 135 CFM, making it well-suited for mid-sized industrial compressed air systems. The polycarbonate bowl provides visible monitoring of collected contaminants, and the manual drain allows controlled removal of accumulated liquids. Maximum allowable system pressure is 150 psi. The modular connection design supports inline integration with compatible PARKER filter and regulator components. Installation is typically performed by instrumentation technicians or industrial maintenance personnel.

The 12F32HC is used in compressed air distribution systems where downstream equipment requires clean, oil-free air. Typical applications include pneumatic tool circuits, process control instrumentation, spray finishing systems, and general plant air conditioning points. The 135 CFM flow rating and 1/2 inch port size place this filter in service on branch lines or point-of-use drops in light to medium industrial environments. The 1 micron filtration rating targets fine oil aerosols that pass through standard particulate filters, protecting downstream valves, cylinders, and instrumentation from contamination-related wear and failure.

Key Features

• 1 micron filtration rating removes fine oil aerosols from compressed air
• 135 CFM flow capacity suits mid-sized branch line and point-of-use installations
• 1/2 inch port size for standard compressed air line connections
• 150 psi maximum working pressure
• Polycarbonate bowl allows visual inspection of collected liquid and contaminant level
• Manual drain for controlled liquid removal without system shutdown
• Modular connection design supports integration with PARKER filter-regulator assemblies

Compatibility

Designed for modular connection with compatible PARKER compressed air filter and regulator components. Consult PARKER documentation for specific modular assembly configurations compatible with the 12F32HC.

Installation Notes

Installation should be performed by a qualified industrial maintenance technician or pneumatic systems specialist. Depressurize and lock out the compressed air system completely before removing or installing any filter element or bowl assembly. Ensure flow direction arrows on the filter body align with the direction of system airflow. Verify that system operating pressure does not exceed the 150 psi rated maximum for this filter.
